SKU:

UPC: 78621054289

Weight: 0.00 LBS

Minimum Purchase: 1 unit

Shipping: Calculated at Checkout

Color:Green

Approval:UL, CSA

Short Description:600 V to 35 kV, 1/2" Stud, 5.23" L, 600 KCMIL, Green, Electro Tin Plated Wrought Copper, 2-Hole, Standard, Straight Barrel, Compression Cable Lug

Material:Electro Tin Plated Wrought Copper

Number of Pad Holes:2

Conductor Size:600 KCMIL (Code)

Voltage Rating:600 V to 35 KV

Series:542

Conductor Material:Copper

Die Index:94

Pad Hole Spacing:1.75

Pad Size:3 L x 1.75 W x 0.24 Thk

Barrel Type:Standard, Straight

Overall Length:5.23

CAD Drawings:ABB-Blackburn_01434_1_CAD.pdf

Catalog:ABB-ColorKeyed_00239_F6-F9_F18_G71_CAT.pdf

Installation/Operator:ABB-ColorKeyed_00016_INST.pdf

Country of Origin:United States
