Name: Eaton EHD3040L Non-Interchangeable Trip Circuit Breaker
Brand: Eaton
Price: 400.44 USD
Availability: InStock

SKU:

Weight: 4.60 LBS

Minimum Purchase: 1 unit

Shipping: Calculated at Checkout

Series:EHD

Short Description:480 VAC 50/60 Hz, 250 VDC, 40 A, 14/10 kA, 3-Pole, Standard Pressure Line and Load Terminal, EHD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker

Frame Type:FD

Number of Poles:3

Maximum DC Voltage Rating:250 V

Maximum AC Voltage Rating:480 V

Interrupting Rating:14 kA at 480 VAC, 10 kA at 250 VDC

Approval:UL 489, CSA C22.2

Catalog:Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Type:Molded Case, Thermal Magnetic

Data Sheet:Eaton_40755_1-4_DATA.pdf

Size:4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height

Voltage Rating:480 VAC 50/60 Hertz, 250 VDC

Terminal Type:Standard Pressure Line and Load

Installation/Operator:Eaton_00091_INST.pdf

TS PIK:21509141
