Name: Eaton EHD2020L Molded Case Circuit Breaker (Repackaged)
Brand: Eaton
Price: 262.28 USD
Availability: InStock

SKU:

Weight: 2.65 LBS

Minimum Purchase: 1 unit

Shipping: Calculated at Checkout

TS PIK:21510801

Frame Type:FD

Voltage Rating:480 VAC, 250 VDC (UL, IEC)

Number of Poles:2

CAD Drawings:Eaton_21583_1_CAD.pdf

Terminal Type:Standard Pressure Line and Load Terminal

Installation/Operator:Eaton_00091_INST.pdf

Series:C, EHD

Maximum DC Voltage Rating:250 V

Type:Molded Case, Thermal Magnetic, Non-Interchangeable

Catalog:Eaton_46579_V4T2_254-V4T2_290_CAT.pdf

Short Description:480 VAC 50/60 Hz, 250 VDC, 20 A, 14 kA, 2-Pole, Line/Load Terminal, EHD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker

Maximum AC Voltage Rating:480 V

Interrupting Rating:14 kA at 480 VAC, 10 kA at 250 VDC (UL, IEC)

Size:2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height

Approval:UL 489, CSA C22.2
